SKF, Eğik Bilyalı Rulman, 7203 BEP, İç Çap: 17mm, Dış Çap: 40mm
Teknik Belgeler
Özellikler
Brand
SKFInside Diameter
17mm
Outside Diameter
40mm
Race Width
12mm
Ball Bearing Type
Single Row Angular Contact Ball Bearing
Sealing Arrangement
Open Type
Bearing Clearance
CN
Material
Steel
Ball Material
Steel
Cage Material
Non-metallic
Number of Rows
1
Static Load Rating
5.5kN
Dynamic Load Rating
10.4kN
Bore Type
Parallel
Bearing Series
2 Light
Partial Bearing Code
7203
Race Type
Plain
Menşe
Australia
Ürün Ayrıntıları
Single Row - Angular Contact - Open Type
These single row angular bearings have a high and low shoulder on both raceways. This allows a large number of balls to be accommodated in the bearing to give it a relatively high loading capacity.
